After moving to the Kreativquartier, we have more Space available and so we decided to build a new Workshop.

Workshop

Specs

Dimensions:

  • width 6,5m
  • length 6m
  • height 3m

Details


Materials

  • Woods
    • 11x OSB4 Panel 1,25x2,5m [1]
    • 30x Kantholz 80x60x3000 [2] to build up wall elements.
    • 4x Kantholz 80x60x3000 [3] to fix things on the floor for additional stability.
    • 1x Kantholz 100x100x3000 [4]
  • Top
    • 4x Acryl plates on top of walls (will be added later if top have to be closed because of dust ) [5]
    • if it seems to be necessary some PVC Foil to close Workshop roof
  • Others
    • Hinges [6]
    • Construction angels
    • Screws
    • Hotglue (If Paul will attend the building phase)

BOM

Part quantity price sum
OSB Panels 11x 21,54€ 236,94€
Kantholz 80x60 30x 4,32€ 129,60€
Kantholz 80x60 4x 4,32€ 17,28€
Kantholz 100x100 1x 13,05€ 13,05€
Hinge 6x 2,20€ 13,20€
Others 1x 100,00€ 100,00€
510,07€
